Cheat Sheet EMC² Symmetrix 1/5

Vérifier les flags d’un directeur sur une baies DMX 4 :

#symmaskdb -sid 3493 list db -dir 10A -p 0 -v

Symmetrix ID : ********3493

Database Type : Type6
Last updated at : 06:02:20 PM on Mon Aug 12,2013

Director Identification : FA-10A
Director Port : 0

Originator Port wwn : 50060b000030c1ce
Type : Fibre
User-generated Name : HIDV007/c1ce
Visibility : No
FCID Lockdown : No
Lun Offset : No
Heterogeneous Host : No
Port Flag Overrides : Yes
Enabled : Common_Serial_Number(C)
Volume_Set_Addressing(V)
SPC2_Protocol_Version(SPC2)
SCSI_Support1(OS2007)
Disabled : N/A
Dynamic Addressing : No
Authentication State : N/A
Devices : 10AA 10BA 10C2 10CA 10D2 15DE 15E3 181D
193A 1942 1A2A 1AFA 1AFE 1B02 1B06 1B0A
1B0E 1B12 1EE3 2048 204C 2050 2054 2058
205C 2060 2064 235C 238D 26F8 26FC 2700
2704 2708 270C 2710 28BD 28BF 28D5 28D7
28D9 28DB 28DD 28DF 28E1 28E3 28E5 28E7
28E9 28EB 28ED 28EF 3044



Originator Port wwn : 10000000c96da2fb
Type : Fibre
User-generated Name : AWIN005/a2fb
Visibility : No
FCID Lockdown : No
Lun Offset : No
Heterogeneous Host : No
Port Flag Overrides : Yes
Enabled : Common_Serial_Number(C)
SCSI_3(SC3)
Disabled : N/A
Dynamic Addressing : No
Authentication State : N/A
Devices : 1D99 23BE:23BF 30DC 30E0



Originator Port wwn : 10000000c9886d30
Type : Fibre
User-generated Name : DE1101A4/6d30
Visibility : No
FCID Lockdown : No
Lun Offset : No
Heterogeneous Host : No
Port Flag Overrides : Yes
Enabled : Common_Serial_Number(C)
SCSI_3(SC3)
SPC2_Protocol_Version(SPC2)
SCSI_Support1(OS2007)
Disabled : N/A
Dynamic Addressing : No
Authentication State : N/A
Devices : 167F 16B7 18B0 2A40



Originator Port wwn : 10000000c98cb5e9
Type : Fibre
User-generated Name : EX9901Q1/b5e9
Visibility : No
FCID Lockdown : No
Lun Offset : No
Heterogeneous Host : No
Port Flag Overrides : Yes
Enabled : Common_Serial_Number(C)
SPC2_Protocol_Version(SPC2)
Disabled : N/A
Dynamic Addressing : No
Authentication State : N/A
Devices : 21B9



Vérifier un DG sur une baie DMX4 :

#symdg -sid 3301 list

D E V I C E G R O U P S

Number of
Name Type Valid Symmetrix ID Devs GKs BCVs VDEVs TGTs

SRVJR1 RDF2 Yes ********3301 211 0 0 0 0
SRVAR1 RDF2 Yes ********3301 1430 0 0 0 0
wks1R1 RDF1 Yes ********3301 1 0 0 0 0
SRV2R1 RDF1 Yes ********3301 2 0 0 0 0
SRVEfR1 RDF1 Yes ********3301 4 0 0 0 0
SRV1R1 RDF1 Yes ********3301 1 0 0 0 0
SRV_p_cl01e2_cl* RDF2 Yes ********3301 8 0 0 0 0
SRVE08_STO RDF1 Yes ********3301 14 0 0 0 0
SRV06_STO RDF2 Yes ********3301 43 0 0 0 0
SRV_p_cl01e2_di* RDF2 Yes ********3301 3 0 0 0 0
SRVBR1 RDF2 Yes ********3301 3 0 0 0 0
SRVGR1 RDF2 Yes ********3301 147 0 0 0 0
SRV_SRV_DISPO RDF2 Yes ********3301 28 0 0 0 0
SRVFR1 RDF2 Yes ********3301 355 0 0 0 0
SRVHR1 RDF2 Yes ********3301 140 0 0 0 0
SRVKR1 RDF2 Yes ********3301 658 0 0 0 0
SRVCR1 RDF2 Yes ********3301 449 0 0 0 0
SRV_p_bdd9_m* RDF1 Yes ********3301 6 0 0 0 0
SRV_p_bdd8_m* RDF1 Yes ********3301 39 0 0 0 0
SRV_p_msq1_m* RDF1 Yes ********3301 2 0 0 0 0



#symSRV show SRV06_STO

Group Name: SRV06_STO

Group Type : RDF2 (RDFA)
Device Group in GNS : No
Valid : Yes
Symmetrix ID : ********3301
Group Creation Time : Fri Mar 20 19:28:02 2009
Vendor ID : EMC Corp
Application ID : SYMCLI

Number of STD Devices in Group : 43
Number of Associated GK’s : 0
Number of Locally-associated BCV’s : 0
Number of Locally-associated VDEV’s : 0
Number of Locally-associated TGT’s : 0
Number of Remotely-associated VDEV’s(STD RDF): 0
Number of Remotely-associated BCV’s (STD RDF): 0
Number of Remotely-associated TGT’s(TGT RDF) : 0
Number of Remotely-associated BCV’s (BCV RDF): 0
Number of Remotely-assoc’d RBCV’s (RBCV RDF) : 0
Number of Remotely-assoc’d BCV’s (Hop-2 BCV) : 0
Number of Remotely-assoc’d VDEV’s(Hop-2 VDEV): 0
Number of Remotely-assoc’d TGT’s (Hop-2 TGT) : 0

Standard (STD) Devices (43):
{
——————————————————————–
Sym Cap
LdevName PdevName Dev Att. Sts (MB)
——————————————————————–
DEV001 N/A 0EB1 WD 6971
DEV002 N/A 0EB2 WD 6971
DEV003 N/A 0EB3 WD 6971
DEV004 N/A 0EB4 WD 6971
DEV005 N/A 18AA WD 27885
DEV006 N/A 18AB WD 27885
DEV007 N/A 18AC WD 27885
DEV008 N/A 18AD WD 27885
DEV009 N/A 18AE WD 27885
DEV010 N/A 18AF WD 27885
DEV011 N/A 1ACC (M) WD 111540
DEV012 N/A 1AD0 (M) WD 111540
DEV013 N/A 1B70 WD 27885
DEV014 N/A 1B6F WD 27885
DEV015 N/A 1B71 WD 27885
DEV016 N/A 1B72 WD 27885
DEV017 N/A 1B73 WD 27885
DEV018 N/A 1B74 WD 27885
DEV019 N/A 19F0 (M) WD 111540
DEV020 N/A 144D (M) WD 111540
DEV022 N/A 147D (M) WD 111540
DEV023 N/A 4252 WD 27885
DEV024 N/A 4253 WD 27885
DEV025 N/A 4254 WD 27885
DEV026 N/A 4255 WD 27885
DEV027 N/A 4256 WD 27885
DEV028 N/A 4257 WD 27885
DEV021 N/A 424C WD 27885
DEV029 N/A 424D WD 27885
DEV030 N/A 4251 WD 27885
DEV031 N/A 425C WD 27885
DEV032 N/A 425D WD 27885
DEV033 N/A 425E WD 27885
DEV034 N/A 4226 (M) WD 111540
DEV035 N/A 4248 (M) WD 111540
DEV036 N/A 4240 (M) WD 111540
DEV037 N/A 4244 (M) WD 111540
DEV038 N/A 1AE2 WD 27885
DEV039 N/A 1AE3 WD 27885
DEV040 N/A 1AE8 WD 27885
DEV041 N/A 1AE9 WD 27885
DEV042 N/A 1B02 WD 27885
DEV043 N/A 1B03 WD 27885
}

Device Group RDF Information
{
RDF Type : R2
RDF (RA) Group Number : 1 (00)

Remote Symmetrix ID : ********3474

R2 Device Is Larger Than The R1 Device : False

RDF Pair Configuration : Normal
RDF STAR Mode : False

RDF Mode : Synchronous
RDF Adaptive Copy : Disabled
RDF Adaptive Copy Write Pending State : N/A
RDF Adaptive Copy Skew (Tracks) : 32767

RDF Device Domino : Disabled

RDF Link Configuration : Fibre
RDF Link Domino : Disabled
Prevent Automatic RDF Link Recovery : Enabled
Prevent RAs Online Upon Power ON : Enabled

Device RDF Status : Ready (RW)

Device RA Status : Write Disabled (WD)
Device Link Status : Ready (RW)

Device Suspend State : N/A
Device Consistency State : Disabled
RDF R2 Not Ready If Invalid : Disabled

Device RDF State : Write Disabled (WD)
Remote Device RDF State : Ready (RW)

RDF Pair State ( R1 <===> R2 ) : Synchronized

Number of R1 Invalid Tracks : 0
Number of R2 Invalid Tracks : 0

RDFA Information:
{
Session Number : 0
Cycle Number : 0
Number of Devices in the Session : 3544
Session Status : Inactive

Session Consistency State : N/A
Minimum Cycle Time : 00:00:30
Average Cycle Time : 00:00:00
Duration of Last cycle : 00:00:00
Session Priority : 33

Tracks not Committed to the R2 Side: 0
Time that R2 is behind R1 : 00:00:00
R2 Image Capture Time : N/A
R1 Side Percent Cache In Use : 0
R2 Side Percent Cache In Use : 0

Transmit Idle Time : 00:00:00
R1 Side DSE Used Tracks : 0
R2 Side DSE Used Tracks : 0
}
}



Retrouver un host à partir d’une LUN sur une baie DMX4 :

#symmaskdb -sid 3474 list assignment -v -dev 21E4

Symmetrix ID : ********3474

Device No. : 21E4

WWN : 10000000c9844080
Type : Fibre
Directors : FA-3A:0

WWN : 10000000c986b456
Type : Fibre
Directors : FA-14A:0

WWN : 10000000c986b457
Type : Fibre
Directors : FA-8C:1

WWN : 10000000c9844081
Type : Fibre
Directors : FA-9C:1



#symmask -sid 3474 list logins | grep 10000000c9844080
10000000c9844080 Fibre MS1102T2 10000000C9844080 050b00 Yes Yes



Supprimer un host sur une baies DMX4 :

#symmaskdb -sid 3474 list capac -host SERV109B

Symmetrix ID : ********3474

Host Name : SERV109B

Identifiers Found : 50060b0000c26a02
50060b0000c26a00

Device Cap(MB) Attr Dir:P
—— ——- —- —-
0E88 – (M) 3B:1,14B:1
1C64 – (M) 3B:1,14B:1
1D60 – (M) 3B:1,14B:1
2009 – (M) 3B:1,14B:1
2105 – (M) 3B:1,14B:1
25F9 – (M) 3B:1,14B:1
292C – (M) 3B:1,14B:1
2930 – (M) 3B:1,14B:1
2934 – (M) 3B:1,14B:1
2938 – (M) 3B:1,14B:1
293A – (M) 3B:1,14B:1
293E – (M) 3B:1,14B:1
2942 27885 3B:1,14B:1
29FE – (M) 3B:1,14B:1
2A45 – (M) 3B:1,14B:1
2A49 – (M) 3B:1,14B:1
2A4D – (M) 3B:1,14B:1
2A58 – (M) 3B:1,14B:1
2A84 – (M) 3B:1,14B:1
2AAD – (M) 3B:1,14B:1
2AB1 – (M) 3B:1,14B:1
2AEA – (M) 3B:1,14B:1
2B27 – (M) 3B:1,14B:1
2B33 – (M) 3B:1,14B:1
2BCE – (M) 3B:1,14B:1
2BD2 – (M) 3B:1,14B:1
2BD6 – (M) 3B:1,14B:1
2BDA – (M) 3B:1,14B:1
2BDE – (M) 3B:1,14B:1
2CBD – (M) 3B:1,14B:1
2D29 – (M) 3B:1,14B:1
2D40 – (M) 3B:1,14B:1
2D7E – (M) 3B:1,14B:1
2D82 – (M) 3B:1,14B:1
2D90 – (M) 3B:1,14B:1
2FFE – (M) 3B:1,14B:1
311E – (M) 3B:1,14B:1
32FE – (M) 3B:1,14B:1
388B – (M) 3B:1,14B:1
3894 – (M) 3B:1,14B:1
3898 – (M) 3B:1,14B:1
389C – (M) 3B:1,14B:1
38DE – (M) 3B:1,14B:1
39A1 – 3B:1,14B:1
417E – (M) 3B:1,14B:1
4182 111540 (M) 3B:1,14B:1
4186 111540 (M) 3B:1,14B:1
418A 111540 (M) 3B:1,14B:1
422E – (M) 3B:1,14B:1
4230 – (M) 3B:1,14B:1
42F9 111540 (M) 3B:1,14B:1
4301 111540 (M) 3B:1,14B:1
4305 111540 (M) 3B:1,14B:1
43B5 111540 (M) 3B:1,14B:1
43B9 111540 (M) 3B:1,14B:1
43BD 111540 (M) 3B:1,14B:1
43C1 111540 (M) 3B:1,14B:1
43F5 111540 (M) 3B:1,14B:1
441D 111540 (M) 3B:1,14B:1
4435 111540 (M) 3B:1,14B:1
443D 111540 (M) 3B:1,14B:1
449D 111540 (M) 3B:1,14B:1
44A1 111540 (M) 3B:1,14B:1
44A5 111540 (M) 3B:1,14B:1
4545 – (M) 3B:1,14B:1
4551 – (M) 3B:1,14B:1
458D – (M) 3B:1,14B:1
4711 – (M) 3B:1,14B:1
4715 – (M) 3B:1,14B:1
4719 – (M) 3B:1,14B:1
471D – (M) 3B:1,14B:1

—————————–

MB Total:1924065
GB Total: 1879.0



#symmask -sid 3474 list logins | grep SERV109B
50060b0000c26a02 Fibre SERV109B 6A02 053101 No Yes
50060b0000c26a00 Fibre SERV109B 6A00 063101 No Yes

#symmask -sid 3474 -wwn 50060b0000c26a02 delete -login

#symmask -sid 3474 list logins | grep SERV109B
50060b0000c26a00 Fibre SERV109B 6A00 063101 No Yes

#symmask -sid 3474 -wwn 50060b0000c26a00 delete -login
